Features
-
Delicate appearance and high portability
-
Enriched trunking functions：The product provides trunking intercom functions, including the individual call, group call, broadcast call, emergency call, call to the dispatch console, PTT speed dial, waiting group, and fail-soft call.
-
Customized industrial applications：The product supports in-depth customization of various industrial applications, such as attendance check in the forestry industry, access control in prisons, and visual dispatch, providing value-added services for customers.
Technical Specifications
|
Item
|
Basic Specifications
|
|
Network support
|
CDMA
|
|
Frequency band
|
800M: 824-849 MHz for transmission, 869-894 MHz for reception
S800M: 806-824 MHz for transmission, 851-869 MHz for reception
|
|
Power
|
Maximum transmission power: 23 dBm
|
|
Dimensions
|
117 mm x 51 mm x 16 mm
|
|
Weight
|
120 g (with the battery)
|
|
Display
|
2.0'' TFT LCD, 176 * 220 pixels
|
|
Operating system
|
BREW
|
|
Battery
|
1300 mAh
|
|
Operating temperature
|
-30ºC to +60ºC
|
|
Storage temperature
|
-40ºC to +80ºC
|
|
Humidity
|
5%-95% RH (non-condensing)
|
|
Protection class
|
None
|
|
Side key
|
PTT key, upper and lower side keys, and camera key
|
|
Camera
|
Rear camera: 1,300,000 pixels
|
|
External interface
|
Mini 8-pin USB (USB 2.0)
Headset interface (mini 8-pin USB interface, compatible with PTT headsets)
|
|
Bluetooth
|
Not supported
|
|
NFC
|
Not supported
|
|
WLAN
|
Not supported
|
|
FM
|
Not supported
|
|
GPS
|
Supported
|
|
Extended storage
|
Micro SD, providing a maximum capacity of 8 GB
|
|
Sensor
|
Not supported
|
|
Charging mode
|
USB
|
Intercom Functions
-
Individual call
-
Group call
-
Broadcast call
-
Emergency call
-
Call to the dispatch console
-
Temporary group call
-
Group auto update
-
Late entry and PTT floor request/preemption/alert tone
-
Inter-group call
-
PTT speed dial
-
Waiting group
-
Fail-soft call
-
GPS locating
