Features
-
Abundant service functions: The product supports GoTa trunking intercom, common voice, SMS messages, and 3G data services.
-
Enriched trunking functions: The product provides trunking intercom functions, including the individual call, group call, broadcast call, emergency call, fail-soft call, waiting group, group auto update, and late entry.
-
Multi-band support: The product supports CDMA 800M, S800M, and 450M frequency bands.
-
Standard PCIe interfaces and flexible AT communication: The product provides a mini PCIe interface for communication with the main control chip. AT instructions can be delivered over USB or UART based on customer requirements.
Technical Specifications
|
Item
|
Basic Specifications
|
|
Network support
|
CDMA
|
|
Frequency band
|
800M: 824-849 MHz for transmission, 869-894 MHz for reception
S800M: 806-824 MHz for transmission, 851-869 MHz for reception
450M Block A: 452.5-457.475 MHz for transmission, 462.5-467.475 MHz for reception
450M Block B: 452.0-456.475 MHz for transmission, 462.0-466.475 MHz for reception
450M Block L: 410.0-414.975 MHz for transmission, 420.0-424.975 MHz for reception
|
|
Power
|
Maximum transmission power: 23 dBm
|
|
Dimensions
|
51 mm x 30 mm x 4.57 mm
|
|
Weight
|
None
|
|
Display
|
None
|
|
Operating system
|
BREW
|
|
Battery
|
None
|
|
Operating temperature
|
-30ºC to +60ºC
|
|
Storage temperature
|
-40ºC to +80ºC
|
|
Humidity
|
5%-95% RH (non-condensing)
|
|
Protection class
|
None
|
|
Side key
|
None
|
|
Camera
|
None
|
|
External interface
|
Mini PCIe
|
|
Bluetooth
|
Not supported
|
|
NFC
|
Not supported
|
|
WLAN
|
Not supported
|
|
FM
|
Not supported
|
|
GPS
|
Supported
|
|
Extended storage
|
None
|
|
Sensor
|
Not supported
|
Intercom Functions
-
Individual call
-
Group call
-
Broadcast call
-
Emergency call
-
Fail-soft call
-
Group auto update
-
Waiting group
-
GPS locating
