Features
-
Professional appearance design and IP54 protection：The product adopts professional appearance design. The spacing between keys meets customer requirements, reducing the possibility of mis-pressing with gloves on. The emergency key and PTT key enable quick operation. The product provides IP54 protection and meets military reliability requirements for prevention against shock, vibration, and solar radiation. This enables the product to adapt to various adverse operating environments.
-
Professional support for accessories：The product provides professional 13-pin interfaces for connecting intercom headsets and hand microphones.
-
Professional acoustic cavity design and perfect audio performance：The product adopts professional acoustic cavity design, generating clear, loud, and high-fidelity voice and meeting the application requirements in noisy operating environments.
-
Enriched trunking functions：The product provides trunking intercom functions, including the individual call, group call, broadcast call, emergency call, call to the dispatch console, PTT speed dial, waiting group, and fail-soft call.
-
Ultra-long standby time：The product provides low power consumption and uses large-capacity batteries to extend the standby time.
Technical Specifications
|
Network support
|
CDMA
|
|
Frequency band
|
800M: 824-849 MHz for transmission, 869-894 MHz for reception
450M Block A: 452.5-457.475 MHz for transmission, 462.5-467.475 MHz for reception
450M Block B: 452.0-456.475 MHz for transmission, 462.0-466.475 MHz for reception
450M Block L: 410.0-414.975 MHz for transmission, 420.0-424.975 MHz for reception
1.9 G: 1850-1910 MHz for transmission, 1930-1990 MHz for reception
|
|
Power
|
Maximum transmission power: 23 dBm
|
|
Dimensions
|
132 mm x 54 mm x 34 mm
|
|
Weight
|
248 g (with the battery)
|
|
Display
|
2.0'' TFT LCD, 176 * 220 pixels
|
|
Operating system
|
BREW
|
|
Battery
|
1700 mAh
|
|
Operating temperature
|
-30ºC to +60ºC
|
|
Storage temperature
|
-40ºC to +80ºC
|
|
Humidity
|
5%-95% RH (non-condensing)
|
|
Protection class
|
IP54
|
|
Side key
|
PTT key, upper and lower side keys, and emergency key
|
|
Camera
|
None
|
|
External interface
|
13-pin USB (USB 2.0)
Headset interface (13-pin USB interface, compatible with PTT headsets)
|
|
Bluetooth
|
Not supported
|
|
NFC
|
Not supported
|
|
WLAN
|
Not supported
|
|
FM
|
Not supported
|
|
GPS
|
Supported
|
|
Extended storage
|
Micro SD, providing a maximum capacity of 8 GB
|
|
Sensor
|
Not supported
|
|
Charging mode
|
Battery charging stand and USB
|
|
Item
|
Basic Specifications
|
Intercom Functions
-
Individual call
-
Group call
-
Broadcast call
-
Emergency call
-
Call to the dispatch console
-
Temporary group call
-
Group auto update
-
Late entry and PTT floor request/preemption/alert tone
-
Inter-group call
-
PTT speed dial
-
Waiting group
-
Fail-soft call
-
GPS locating
